Beskrivelse
Stylus Type: Spherical
Stylus Tip Radius: R 26 uM
Tracking Force Range: 3,0-5,0 g (30-50 mN)
Tracking Angle: 20°
Internal Impedance (DC Resistance): 750 Ohms
Internal Inductance: 450 mH
Load Resistance: 47 k Ohms
Load Capacitance: 200 – 600 pF
Compatible Cartridges: Pro S Series
Output Voltage (1000Hz, 5cm/Sec): 5 mV
Channel Balance (1kHz): 2 dB
Channel Separation (1kHz): 20 dB
Channel Separation (15kHz): 15 dB
Frequency Range (-3 dB): 20 – 20,000 Hz
Frequency Response: 20 – 18,000 Hz (+/- 2 dB)
Tracking Ability (315 Hz): 70 uM
